Electromagnetic Relay, NSN: 5945-01-105-9837, P/N:17831, New!

AVO Intl

$ 14.00


Electromagnetic Relay

NSN: 5945-01-105-9837

P/N:17831

Overall Length:  2.220 inches nominal
Overall Width:  1.530 inches nominal
Environmental Protection:  Dust tight
Frequency in Hertz:  50.0 minimum and 60.0 maximum
Coil Quantity:  1
Mounting Facility Type and Quantity:  1 plug-in terminal single mounting facility
Pile-up Main Contact Form Arrangement:  3C
Nominal Operating Current Rating and Type:  30.0 amperes ac single winding
Operating Voltage Rating and Type at Specified Temp:  120.0 volts ac nonstandard temp single winding
Minimum Differential Electrical Operating Rating:  1.5 watts
Main Contact Load Current Rating at Maximum Rated Voltage:  15.0 amperes ac inductive load
Main Contact Maximum Voltage Rating in Volts:  240.0 ac

Condition: New, has been in storage.
