Electrical Receptacle Connector
NSN: 5935-00-410-1344
Part Numbers: 87377-2, 1-85930-8, 1-86206-5, 1-87377-2, 189158-15, DMS 89055B
Body Style: Rectangular shape
Overall Length: 2.440 inches
Body Width: 1.250 inches
Environmental Protection: Thermal shock resistant
Mating End Quantity: 1
Contact Position Arrangement Style: 2 rows of contacts non-inserted board single mating end
Contact Removability: Removable single mating end single contact grouping
Contact Maximum Current Rating In Amps: 3.0 single mating end single contact grouping
Terminal Location: Back single mating end single contact grouping
Contact Surface Treatment: Gold single mating end single contact grouping
Contact Surface Treatment Specification: MIL-G-45204 military specification single treatment response single mating end single contact grouping
Terminal Type: Crimp single mating end single contact grouping
Included Contact Quantity: 48 single mating end single contact grouping
Included Contact Type: Round pin single mating end single contact grouping
Precious Material And Location: Contact surfaces gold
Precious Material And Weight: 0.048 gold grains, troy
Precious Material: Gold
Condition: New
